Engines
P&W PT6A-42, HOTS November 2021, 1,839 TTSN, 2,218 CSN.
Avionics Information
AVIONICS: Rockwell Collins Pro Line 21
AIR DATA COMPUTER: Dual Collins ADC-3000 Air Data Computers ATTITUDE HEADING REFERENCE SYSTEM: Dual Collins AHC-3000 (AHRS) AUTOMATIC DIRECTION FINDER: Single Rockwell Collins ADF AUTOPILOT: Dual Rockwell Collins FGC-3000 Flight Guidance Computers COCKPIT VOICE RECORDER: L3 FA2100 CVR (120 Minutes) COMMUNICATIONS: Dual Rockwell Collins VHF-4000 Radios with 8.33KHz Spacing DATABASE LOADER: Rockwell Collins DBU-5010E DISPLAYS: Rockwell Collins AFD-3010 Pilot, Co-Pilot, and MFD Displays DISTANCE MEASURING EQUIPMENT: Rockwell Collins DME-4000 ENHANCED GROUND PROXIMITY WARNING SYSTEM: Honeywell Mark VIII EGPWS EMERGENCY LOCATOR TRANSMITTER: Artex C406-2 ELT FLIGHT MANAGEMENT SYSTEM: Rockwell Collins FMC-3000 FMS GLOBAL POSITIONING SYSTEM: Rockwell Collins GPS-4000A VHF NAVIGATION: Rockwell Collins NAV-4000 and NAV-4500 VHF Nav Receivers RADIO ALTIMETER: Single Rockwell Collins ALT-4000 Radio Altimeter RADIO TUNING: Rockwell Collins RTU-4220 TRAFFIC COLLISION ALERT AND AVOIDANCE SYSTEM: Rockwell Collins TCAS with Change 7.0 TRANSPONDER: Dual Rockwell Collins TDR-94D Transponders with Enhanced Surveillance and Flight ID WEATHER RADAR: Rockwell Collins RTA-852 Weather Radar WAAS/LPV
Interior Information
Seven passenger interior featuring two aft-facing club seats in the forward cabin, followed by a 4-person club seat arrangement in the aft cabin with fold-out side ledge tables on either side. A galley station in the forward cabin features two plug-in coffee pots and storage drawers beneath. Four 115 VAC 60Hz electrical outlets are available in the cabin area along the bottom of the dado panels. The cockpit and baggage bay can be isolated from the cabin by pocket doors in the forward and rear cabin bulkhead. A seventh seat is located in the baggage bay area opposite the main entrance door and features a chemical toilet beneath the fold-up seat.
Other Equipment / Information
ADDITIONAL FEATURES BLR Winglet System TCAS II w/change 7 Electronic Standby Indicator 77 Cubic Feet Oxygen Bottle Quick Don Pilot Oxygen Masks Heated Propeller De-Ice System 115 VAC / 60 Hz Electrical Outlets in Cabin Approach Chart Holder with Digital Clock Forward and Aft Cabin Pocket Doors Aircell ST 3100 Iridium Phone System
Inspection Status
MAINTENANCE STATUS Aircraft enrolled on CAMP INSPECTIONS LAST COMPLETED NEXT DUE Phase 1 11/2/2021 11/1/2023 Phase 2 11/2/2021 11/1/2023 Phase 3 12/30/2020 11/1/2022 Phase 4 12/30/2020 11/1/2022
|
